DRI Scope
DRI stands for Detection, Recognition and Identification.
| people | SUV | truck | |
| Target size | 1.8*0.5m | 4.2*1.8m | 6*4m |
| Detection distance | 542m | 1661m | 2889m |
| Recognition Distance | 135m | 415m | 722m |
| Identification distance | 68m | 208m | 361m |
The standard configuration is Autel smart remote controller V3, with a 7.9-inch 2000nits high-brightness screen that is not afraid of strong light and clearly presents real-time information; based on Autel SkyLink2.0 image transmission technology, it ensures the anti-interference of signal transmission, and users can complete the operation and settings of the drone at a distance of up to 15 kilometers; with a customized Android system, users can download and install third-party apps to make work more efficient.
| 7.9-inch HD touch screen | -20~40°C operating temperature |
| 2000 nits peak brightness | IP43 Protection Rating |
The CMOS uses an RYYB array and can directly output 50-megapixel photos to discover more details, assist in evidence collection, and achieve accurate judgment. At the same time, thanks to the super-sensitive algorithm 2.0, it has excellent noise suppression capabilities under low-light conditions, and can still shoot clean and clear 4K night scene videos using high ISO.
Equipped with a 1/1.28-inch CMOS, compared to the common 1/2-inch or 1/2.3-inch CMOS on the market, the area is 144~233% larger, showing more image details.
The RYYB array-designed CMOS can receive 40% more light than the traditional RGGB, ensuring sufficient light input in low-light environments.
Hybrid focus technology combines the fast focusing of phase detection autofocus (PDAF) and the precise focusing of contrast detection autofocus (CDAF), enabling fast and accurate capture of moving targets.
Center temperature measurement: Real-time display of the temperature in the center area of the screen.
Point temperature measurement:Click the screen and the temperature of the object you are pointing to will be displayed in real time.
Regional temperature measurement: Dynamically display the average temperature, maximum temperature.
Minimum temperature: The area size can be modified and moved, and the hot and cold spots are dynamically displayed in the area.
Temperature alarm: It can monitor the screen temperature in real time. When the temperature reaches the set threshold, the system will automatically prompt.
Isotherms: For different objects, the temperature range can be displayed in real time to assist in quickly troubleshooting the target object.
Image enhancement: Supports real-time adjustment of image brightness, contrast, and image details to highlight the temperature measurement target.
White heat|Cold heat|Rainbow|Enhanced rainbow|Iron red|Lava|Aurora|Scorching|Gradient|Heat detection
IRPCTOOL: A free temperature measurement analysis tool developed for the 640T temperature measurement version, which allows users to quickly import images, edit and analyze temperature measurements, and quickly generate reports for easy archiving and sharing.
The infrared thermal imaging image is effectively integrated into the center of the visible light image. While observing the infrared thermal imaging image, the visible light image is used to obtain clear environmental information in real time to quickly locate the root cause of the problem.
